Applicability
Longer and wider products such as flooring boards, windows, big boxes, wood pallets, etc.
|
MODEL
|
RSG-1000
|
|
Sealing Type
|
Four Sides Sealing, Full Closed Sealing
|
|
Installed Power
|
380V/50-60HZ/3Phase
|
|
Packing Capacity
|
5-10 Packs per Minute (Depends on Product Size)
|
|
Sealing Height
|
500MM
|
|
Packing Width
|
1400MM
|
|
Product Size
|
Width + Height ≤ 1400MM
|
|
Film Type
|
Single layer POF/ PE Film
|
|
Max Film Roll Size
|
1800MM (Width) X 280MM (Outer Diameter)
|
|
Power Consumption
|
5 KW
|
|
Working Height
|
780-850 MM
|
|
Air Pressure
|
0.5MPA (5 BAR)
|
|
Sealing Knife
|
Special Durable Alloyed Sealing Knife with Anti-Stick Teflon Coats
|
|
Operating Panel
|
Siemens Colorful Touch Screen, PLC
|
|
Sealing Machine Weight
|
1980KGS
|
|
Sealing Machine Dimensions
|
2300 X 1500 X 1100 MM
|
|
SHRINK TUNNEL
|
|
Oven Size
|
Depends on product size
|
|
Conveyor Speed
|
Variable, 40 M/Min
|
|
Working Height
|
780 - 850 MM
|
|
Machine Material
|
Carbon Steel
|
|
Tunnel Machine Dimensions
|
2500 X 1100 X 1270 MM
|
|
Tunnel Weight
|
1835KGS
|
Part 4 Bag Collecting Machine
|
|
|
|
The new type bag collecting machine adopts the visual operation of the computer display screen. According to the need, the pre-set quality can be as many as one dozen, which is convenient to collect neat bag.
|
Part 4 Bag Collecting Machine
|
|
|
|
The new type bag collecting machine adopts the visual operation of the computer display screen. According to the need, the pre-set quality can be as many as one dozen, which is convenient to collect neat bag.
|
